ISDT RC Electronic Speed Controller,ESC70 WP 1080 70/120A Brushed Motor Electronic Speed Controller,Smart ESC with Brake Waterproof for RC Car 1:10 1:8 Model(2-3S LiPo/6-8S NiMH)

Item Brand:ISDT

Model:ESC70

Cont./Peak Current:70/120A

Motor Type:540/550/775 Brushed Motor

Application:1/8 1/10

Support batteries:Lipo(2-3S)/NiMH(6-8S)

BEC Output:3A amp rating,5V-7.5V Switch (Stepping 0.1V)

Wire/Connectors:16AWG 200mm / No

Explanation for LED Status

Power On:Short press once-white LED flashes

Standby:Green LED on

Error:Red LED flashes

Bluetooth to be connected:Long press 5 seconds before use to enter setting Blue LED flashes

Bluetooth Connected: Blue LED ON

Power Off: Long press once

Package included:

1X 70A ESC

Product Dimensions ‏ : ‎ 3.86 x 3.16 x 1.71 cm; 75 g
Date First Available ‏ : ‎ 16 Mar. 2022
Manufacturer ‏ : ‎ Nova new energy
ASIN ‏ : ‎ B09VPWDQ2S
Item model number ‏ : ‎ ESC-70
Country of origin ‏ : ‎ China
Guaranteed software updates until ‏ : ‎ unknown

【Bluetooth connection function】 You can establish a wireless connection with your mobile phone without extra accessories. The mobile App has multiple programmable parameter settings, real-time data query, OTA upgrade and other operations. It is powerful, convenient and easy to use.
【Precise adjustment】 0.1V step adjustment, curve adjustment of brake and accelerator parameters, allowing users to be more handy and manipulative, and accurately adjust the forward power and braking force of the motor,specially designed for RC Crawler that characteristics operating on toughest terrain.
【Advanced BEC Function】Built-in BEC with adjustable output functions,outputs up to 3A continuous current and supports 5V to 7.5V via ISD Go APP. Supports various powerful RC applications and high voltage servos.
【Multiple protection functions】battery low voltage protection, over temperature protection, throttle out of control protection, BEC overvoltage and undervoltage protection.
【Strong waterproof performance】Fully waterproof design for all conditions. (Note: Please clean and maintain after use to avoid corrosion)
