Upgraded Fuel Injector Tester and Cleaner Kit with 8 Pulse Modes 4 Injector Cleaner Adapter 12V/5V Output Power Modes Short Circuit Protector Clean Two Fuel Injectors Simultaneously DIY Cleaning Tool

Product Description

The electronic activator has several modes that automatically work the injectors with single or multiple pulses. It receives power from a 12 volt car battery and it sends power to leads plugged to up to 2 injectors. You select the mode then press enter and you can press enter again and it will activate again, or change the mode for a different selection of how many times the injector will open. Fuel injector tester can help you diagnose injector problems and can be used to test injectors one by one or two at the same time to help confirm sticking, leaking, damage or burnout conditions.

Mode 0: standby state, no output

Mode 1: Single pulse low power mode, in this mode, when the PULSE key is pressed, the instrument will send out a pulse with a pulse width of about 255 milliseconds.

Mode 2: short pulse low power mode, in this mode, when the PULSE key is pressed, the instrument will send out 50 pulses with a pulse width of about 7 milliseconds.

Mode 3: long pulse low power mode, in this mode, when the PULSE key is pressed, the instrument will send out 100 pulses, and the pulse width is about 3.5 milliseconds.

Mode 4: continuous pulse low power mode, in this mode, when the PULSE key is pressed, the instrument will output pulses continuously, the pulse rate is about 50 pulses every 1450 milliseconds, and the pulse width is about 7 milliseconds.

Note: During the pulse output period, the MODE SET button is invalid, and the working mode can only be selected by pressing the PULSE button again to terminate the output

Mode 5: Single pulse high power mode, in this mode, when the PULSE key is pressed, the instrument will send out a pulse with a pulse width of about 255 milliseconds.

Mode 6: short pulse high power mode, in this mode, when the PULSE key is pressed, the instrument will send out 50 pulses with a pulse width of about 7 milliseconds.

Mode 7: Long pulse high power mode, in this mode, when the PULSE key is pressed, the instrument will send out 100 pulses, and the pulse width is about 3.5 milliseconds.

Mode 8: continuous pulse high power mode, in this mode, when the PULSE key is pressed, the instrument will output pulses continuously, the pulse rate is about 50 pulses every 1450 milliseconds, and the pulse width is about 7 milliseconds.

Note: During the pulse output period, the MODE SET button is invalid, and the working mode can only be selected by pressing the PULSE button again to terminate the output

Power supply : 12V battery or DC 12V (recommended 2A) power adapter

Working conditions: 0°C-40°C; relative humidity ≤80%

Storage conditions: -20°C-50°C; relative humidity ≤85%

Size : 120*80*25mm (main part only)

Weight : 0.34kg

Kind tips:

1. Before using this instrument, the engine of the car must be turned off.

2. Do not smoke or ignite near the car.

3. Do not splash the fuel of the car on the hot engine parts.

4. Only use this instrument in a ventilated place.

5. Do not get close to any rotating (or moving) parts of the car, and do not touch any heat-generating parts of the car.

6. Do not short-circuit the positive and negative poles of the car battery.

7. Do not touch any car parts with dangerous voltage.

8. Wear qualified goggles.

9. After the test is complete, all disconnected vehicle connections should be properly restored.

1. Turn off the car’s engine.

2. Remove the wire plug of the vehicle injector to be tested, and then connect the two pulse output terminals of the instrument to the vehicle injector.

3. Then connect the red clip of the instrument to the positive terminal of the 12V car battery, and connect the black clip of the instrument to the negative terminal of the car battery.

4. Insert the DC plug into the port of the instrument

5. Press MODE SET key to select the desired pulse signal output mode, and the screen will display the currently selected mode.

4 wire 2 test channel

In the meantime, you can t est and compare the work result of two injectors. Greatly improve overall work efficiency.

1m power cord

The extended 1m power cable is more than twice that of other brands’ injector tester. Provide more flexible operation.

4 nozzle adapters

The automotive fuel injector tester can be used with any fuel pressure tester to easily clean and test most car and motorcycle fuel injectors.

DC Input Port ( 12V )

Power supply : 12V battery or DC 12V (recommended 2A) power adapter

Packaging details

1 * Fuel Injector Tester

1 * Carrying Bag

1 * Instruction manual

2 * Battery clips

4 * Injector Adapters

4 * Pulse Output Terminal Test Wires

【Upgraded Ideal Tools】The fuel injector tester is designed with 8 pulse modes and LED display indicator lights. It features advanced cleaning and diagnostic capabilities, allowing you to easily diagnose and fix injector issues such as blockage, leakage, damage, and burnout. It is consisting of 4 pulse signal output modes(short/medium/long/continuous pulse) with 2 output Power(12V/5V) to check conditions of the injectors.
【Testing Two Injectors Simultaneously】The fuel injector tester tool has two pairs of output terminals which can test two fuel injectors at the same time for making a better judgement.
【4 Pulse Signal Output Modes & 8 Pulse Modes】Fuel injector cleaner kit has two output voltage levels and 4 pulse signal output modes(short/medium/long/continuous pulse mode),with the continuous pulse mode helping to identify good and bad injectors.In addition,fuel injection cleaner has high and low power drive modes,which can test injectors under various powers.Compared with the injector testers on the market that only have high power modes,the functions are more comprehensive.
【4 Injector Cleaner Adapters】This fuel injector cleaner set comes with 2 different sizes of adapters(2 pieces 14mm and 2 pcs 11mm) to connect the injector nozzle and cleaning liquid. The adapters can fit most types of car motorcycle fuel injectors except Cylinder Direct-Injection Nozzle.
【Reverse Polarity and Short Circuit Protection】The tester kit is designed with input power reverse polarity protection and output short circuit protection. The LED indicator will give an alert if there are any fuel injector damaged or output pulse short circuit happen.
